[In-Stock] Neo70

Details

DOESN'T INCLUDE PLATE YET, PLEASE ADD IT SEPARATELY BEFORE CHECKING OUT.

This batch of in-stock units are from the first pre-order back in November 2023.

Another round of pre-orders will be run once these in-stock units sell out.

The Neo70 is the second installment in the Neo family of custom mechanical keyboards. This FRL-TKL board features an innovative magnetic connector for the PCB and daughterboard, making assembly and disassembly incredibly easy without the need of JST or Ribbon cables.

For full product information, check out the Neo70 Notion page here.

Specs

• Typing angle：8 degrees
• Front height：17.5 mm
• Size：356.5mm * 107.8mm
• Weight：
  • with aluminum weight: 0.89kg before building, 1.26kg after building
  • with copper weight: 1.16kg before building, 1.53kg after building
  • with stainless steel weight: 1.13KG before building, 1.5kg after building
• PCB Specs

  • Tri-mode Hotswap PCB (Non-flex Cut)
    • 1.6mm thick
    • Support USB-C, Bluetooth, and 2.4GHz connection
    • Support both ANSI and ISO layout
    • NKRO
    • Polling rate: 1000Hz in wired and 2.4Ghz mode; 125Hz in BT mode
  • Wired Hotswap PCB (Non-flex Cut)
    • 1.6mm thick
    • USB-C connection only
    • Support both ANSI and ISO layout
    • NKRO
    • Polling rate: 1000Hz
    • NO Per-key RGB
  • Solder PCB (Non-flex Cut)
    • 1.6mm thick
    • USB-C connection only
    • Support both ANSI and ISO layout
    • NKRO

    • Polling rate: 1000Hz
  •

Package Contents

• Case
  • Including one pre-installed external weight of your choice
  • Including one pre-installed badge of your choice
  • One 3000mAh battery will be installed inside the case for orders with Tri-mode PCBs
  • Orders with wired PCBs or solder PCBs will receive fillers for the battery compartments
• PCB Kit

• PCB of your choice
• 1x PE sheet
• 1x PCB Foam
• Standoffs
• Tri-mode PCB comes with a 2.4Ghz dongle
• Plate of Your Choice (or Plateless with Solder PCB)

• Poron Case Foam
• PCB Daughterboard * 3 - installed
• SiliconeGaskets
• O-ring (30 duro) x 1
• Rubber feet
• Free Gifts (Not covered by warranty):
  • Keyboard carrying case
  • 1x Keycap & Switch puller
  • 1 set of 70% PCB clip-in NeoStab
  • USB-C cable
