Details
FREE SHIPPING WITHIN MALAYSIA (EAST MALAYSIA INCLUDED)
Ships to Malaysian and Bruneian Addresses Only.
1 UNIT PER ORDER, YOU CAN PLACE MULTIPLE ORDERS
Pre Order Start Date: 24 Feb 2025
Pre Order End Date: 9 March 2025, 11:59 PM
Estimated Fulfilment: May 2025
For further information on the product, check it out at QK's Notion Page.
Check the full configurator on QK's website here
Please note:
- Plates designed for plate-mount stabilizers only support the 6.25u spacebar ANSI layout. For 7u spacebar or ISO layout builds, please choose PCB-stab plates.
- Although the plate-stabilizer plate is compatible with the WKL case, the bottom row must be built in a 1.5u + 1.25u + 6.25u + 1.25u + 1.25u + 1.5u layout. For most users' typing preferences, we recommend using PCB-stabilizer plates with the WKL case.
- Spray-coated Black* case contains micro-glitter.
- Per-key RGB lighting significantly increases power consumption, substantially reducing the keyboard's battery life in wireless modes. If you're not a big fan of per-key RGB, we strongly recommend choosing the non-RGB PCB for better battery performance.
- Renders are for reference only. Please note that actual product colors may vary under different lighting conditions. Color differences between the render and the actual product will not be considered a quality issue.
- Mass-produced product uses Torx case screws instead of Phillips screws.
Specs
- Typing angle: 7 degrees
- Front height: 19mm
- Size: 133mm * 442mm
- Weight: 1.855kg before build
PCB Specs
All PCBs:
- USB-C, Bluetooth, and 2.4GHz connections
- Compatible with both ANSI and ISO layouts (ISO layout requires PCB-mount stabilizer plate)
- Support both WK and WKL layouts
- Compatible with both 6.25u and 7u spacebars (7U requires PCB-mount stabilizer plate)
- Using QK's custom VIA web configurator for keymapping and screen customization, as standard VIA doesn't support advanced screen functions
- Tri-mode Flex-cut Hotswap PCB w/Per-key RGB
- 1.2mm thick
- Per-key RGB
- Tri-mode Flex-cut Hotswap PCB
- 1.2mm thick
- No Per-key RGB
- Tri-mode Non-flex cut Hotswap PCB
- 1.6mm thick
- No Per-key RGB
Package Contents
- Keyboard case
- Includes pre-installed screen module and screen daughterboard
- Includes two pre-installed 4000 mAh batteries
- Includes four pre-installed rubber feet
- Includes pre-installed PCB daughterboard with magnetic connector
- Includes 2.4GHz USB dongle stored under the back badge
- PCB Kit
- PCB of your choice
- PET sheet (included only with per-key RGB PCB)
- IXPE sheet
- PCB Foam
- Plate of your choice
- Case foam and anti-static protective film
- Silicone gaskets and LED diffusers
- Top-mount mounting screws
- Free gifts (Disclaimer: If any of these gifts are missing or damaged, they will not be re-shipped or replaced):
- Switch and keycap puller
- Phillips screwdriver and Torx screwdriver
- USB-C cable
- Keyboard protective case
- Stabilizers (type varies based on plate selection)
- Complimentary front badge
- Backup rubber feet
Pre Order Policy and Disclaimer
- Strictly no refunds/cancellations after Pre Order period has ended. 5% processing fee applicable for refunds/cancellations during the Pre Order period.
- Do not mix Pre Order and non Pre Order items in the same order, as well as items from different Pre Orders/GBs in the same order.
- This is a group buy/pre-order item. By placing an order you agree with the delivery date and acknowledge that the date may be subject to changes due to manufacturing or shipping delays.
- By placing an order, you agree to the terms stated above.
